Gantry Plasma Cleaning

Technical Excellence

The Gantry Plasma Cleaning Machine is an industrial plasma cleaning solution developed for lithium battery manufacturing applications. It is designed to clean battery pole surfaces and improve surface adhesion, helping prepare cell poles for subsequent manufacturing and joining processes.

The machine features a servo-driven XYZ gantry system that moves the plasma cleaning head to individual battery cell poles. During operation, the battery pack is manually positioned inside the machine, the gantry moves the cleaning head to the required locations, and the cleaned battery is manually removed after the process is completed.

With adjustable output power ranging from 400 W to 1200 W, an operating frequency of 18–40 kHz, and a maximum cleaning area of 800 × 600 mm, the SI-R GPC-1200W provides configurable cleaning parameters for suitable production requirements. Its industrial computer, 19-inch widescreen display, and four 400 W servo motors support machine operation and gantry movement.

The Semco Gantry Plasma Cleaning Machine is suitable for manufacturers seeking a dedicated plasma cleaning process for lithium battery poles. It can be integrated into battery production workflows where surface preparation and adhesion improvement are important process requirements.

Line Speed

6m / 7m / 8m

Dimensions

40 ft – 200 ft

Power Requirement

20 kW – 200 kW

Key Fixture Features

  • XYZ Gantry Motion System: Servo-driven movement of the plasma cleaning head along the X, Y, and Z axes.
  • Adjustable Plasma Output: Configurable output power from 400 W to 1200 W for suitable cleaning requirements.
  • Lithium Battery Pole Cleaning: Designed specifically for plasma cleaning of lithium battery pole surfaces.
  • Enhanced Surface Adhesion: Plasma treatment helps improve surface adhesion before subsequent manufacturing processes.
  • Large Cleaning Area: Supports a maximum cleaning area of 800 × 600 mm.
Laser Cleaning Machine

Request a Quote

Looking for the right solution? Our experts are here to guide you with specifications, customization options, and pricing details.
The Semco Gantry Plasma Cleaning Machine (SI-R GPC-1200W) is designed for precision cleaning of lithium battery cell pole surfaces to enhance surface adhesion. Equipped with an XYZ gantry motion system and adjustable plasma output power from 400 W to 1200 W, the machine enables controlled cleaning across battery cell poles. Its maximum cleaning area of 800 × 600 mm makes it suitable for lithium battery manufacturing and battery pack production applications.

Suitable for industries such as:

EV battery production, energy storage manufacturing, battery research labs, electronics assembly, and OEM-based fabrication units.

Parameter Specification
Product name Semco Gantry Plasma Cleaning Machine
Model SI-R GPC-1200W
Equipment type Gantry plasma cleaning system
Plasma output power 400–1200 W, adjustable
Operating frequency 18–40 kHz
Maximum cleaning area 800 × 600 mm
Gantry travel 800 × 600 × 400 mm
Input gas connection Ø8 mm pipe
Output gas pressure 0.1–0.40 MPa
Input power supply 220 VAC
Maximum machine power ≤ 6 kW
Machine weight Approximately 200 kg
Servo motors 4 × 400 W
Display 19-inch widescreen
Industrial computer i7 + 128 GB, as listed
Equipment dimensions 1600 × 1350 × 1950 mm, as listed in the parameter table

Product Name

Description

Applications

This product is used for:

  • Lithium-ion battery assembly and production units
  • EV battery manufacturing facilities
  • QC and testing labs
  • R&D facilities
  • OEM and contract manufacturing plants
  • Plasma cleaning of lithium battery pole surfaces.
  • Surface preparation of battery cells before subsequent manufacturing processes.
  • Improving surface adhesion on suitable battery pole materials.
  • Cleaning individual cell poles using an XYZ gantry motion system.
  • Battery pack manufacturing and assembly workflows requiring pole surface preparation.
  • Lithium-ion battery production environments where controlled plasma treatment is required.
  • Manufacturing processes that require repeatable positioning of a plasma cleaning head across multiple cell poles.

Support & Warranty

  • Technical Consultation: Assistance with equipment specifications and application suitability.
  • Installation Guidance: Support for equipment installation and initial setup, subject to the agreed project scope.
  • Operating Guidance: Assistance with understanding machine operation and recommended cleaning parameters.
  • Maintenance Support: Guidance on routine inspection and equipment maintenance.
  • Warranty duration and coverage are subject to Semco Infratech's official quotation and purchase agreement.
  • Warranty claims are handled according to the agreed terms and conditions.

Reviews

There are no reviews yet.

Be the first to review “Gantry Plasma Cleaning”

Your email address will not be published. Required fields are marked *

Faq

Frequently Asked Questions

Find quick answers to common questions about our BESS Assembly Line, including automation capabilities, supported battery types, customization options, safety standards, and production scalability.

What is a BESS Assembly Line?
A BESS Assembly Line is an automated system used to assemble battery energy storage modules and packs efficiently and accurately.
It is used to produce battery modules, battery packs, and complete energy storage systems.
Yes, the line supports fully or semi-automated operations based on production requirements.
It supports lithium-ion batteries including prismatic, cylindrical, and pouch cells.
How is product quality ensured?
In-line testing, vision inspection, and automated checks ensure consistent quality and reliability.
Yes, the assembly line can be customized to match specific capacity, layout, and production needs.
The system includes safety interlocks, fault detection, and controlled assembly environments.
Yes, it is designed for high-throughput and scalable manufacturing.

Faq

Frequently Asked Questions

Find quick answers to common questions about our BESS Assembly Line, including automation capabilities, supported battery types, customization options, safety standards, and production scalability.

A gantry plasma cleaning machine uses plasma treatment to clean surfaces. The Semco SI-R GPC-1200W is designed to clean lithium battery pole surfaces and enhance surface adhesion.
It is used for plasma cleaning of lithium battery poles. The machine moves its cleaning head to individual battery cell poles using a servo-driven XYZ gantry system.
The machine has adjustable plasma output power ranging from 400 W to 1200 W.
The specified maximum cleaning area is 800 × 600 mm, with XYZ gantry travel of 800 × 600 × 400 mm.
The operator manually places the battery pack inside the machine. The XYZ gantry then moves the plasma cleaning head to clean individual battery cell poles. Once cleaning is complete, the operator manually removes the battery.
Yes. Plasma treatment is intended to enhance surface adhesion. The actual results depend on the battery pole material, surface condition, and process parameters.
The specified operating frequency range is 18–40 kHz.
The machine uses a 220 VAC input power supply and has a maximum rated machine power of 6 kW or less.
Semco
A gantry plasma cleaning machine uses plasma treatment to clean surfaces. The Semco SI-R GPC-1200W is designed to clean lithium battery pole surfaces and enhance surface adhesion.
It is used for plasma cleaning of lithium battery poles. The machine moves its cleaning head to individual battery cell poles using a servo-driven XYZ gantry system.
The machine has adjustable plasma output power ranging from 400 W to 1200 W.
The specified maximum cleaning area is 800 × 600 mm, with XYZ gantry travel of 800 × 600 × 400 mm.
The operator manually places the battery pack inside the machine. The XYZ gantry then moves the plasma cleaning head to clean individual battery cell poles. Once cleaning is complete, the operator manually removes the battery.
Yes. Plasma treatment is intended to enhance surface adhesion. The actual results depend on the battery pole material, surface condition, and process parameters.
The specified operating frequency range is 18–40 kHz.
The machine uses a 220 VAC input power supply and has a maximum rated machine power of 6 kW or less.
