Neware Cell Tester 5V 100A 16CH


5V 20A 64CH     5V120A-4CH    5V 200A 4CH
5V 30A 16CH     5V 200A 4CH    5V 500A 2CH
5V 30A 8CH     5V 300A 6CH    5V 800A 2CH
5V 60A 32CH     5V 300A 2CH    5V 800A 4CH
5V 60A 48CH     5V 300A 4CH
5V 60A 48CH     5V 200A 8CH
5V 100A 4CH     5V 200A 16CH
5V 100A 16CH     5V 200A 16CH
5V100A-32CH     5V 200A 24CH
Inquire Now
Please enable JavaScript in your browser to complete this form.


Input Impedance ≥1MΩ



CV output range 0.025V~5V
Min discharge voltage 2V
Accuracy ± 0.05% of FS
Stability ± 0.1% of FS



Output range/channel 1A~200A
Accuracy ± 0.1% of FS
CV cut-off current 0.4A
Stability ± 0.1% of FS


Output power/channel 1000 W
Stability ± 0.2% of FS


Current response time Max rising time: 20ms
Working step time ≤(365*24)h/step, Time format-00:00:00.000(h:m:s:ms)

Data record

Data record conditions Min data record interval:100ms
Min voltage change:10mV
Min current change:400mA
Frequency 10Hz



Charge mode Constant current, Constant voltage, Constant current and voltage, Constant power
Cut-off condition Main channel:Voltage, Current, Δ Time, Capacity, -ΔV



Discharge mode Constant current, Constant power, Constant resistance, Support Customize constant current and voltage
Cut-off condition Main channel:Voltage, Current, Δ Time, Capacity, -ΔV



Pulse Mod


Charge Constant Current, Constant Power
Discharge Constant Current, Constant Power
Min pulse width 500ms
Pulse Cycle up to 32
Charge and Discharge switch Auto Switched
Cut-off condition Voltage, Time
DCR Support DCR Calculation Based on User-Defined Record
Parallel Mode Maximum support 4 channel parallel ,Pulse and Simulation are not available after parallel mode
