Features:

1. Over Charging and over discharging protection test.
2. Over Charging delay time and over Discharging delay time protection test.
3. Short circuit protection test.
4. Over voltage/under voltage protection tests.
5. Over voltage delay time /under voltage delay time protection test.
6. Over voltage/under voltage release protection test.
7. Single cell self-consumption test.
8. Total self-consumption test of protection board.
9. Equalization current & Equalization voltage.
10. Precise testing and quick test.
11. IR Testing.
12. Type of BMS test support – B+, P+, C+, B-, P-, C-.

Technical parameter

• High current module: the current level is 150A, current accuracy 0.1A.
• Voltage module: voltage range 0.5-5V, programmable output 0.5-5V, voltage accuracy 5mV.
• Short circuit module: super capacitor, fully analog pack battery voltage, instantaneously short the protection board circuit to accurately capture the short-circuit time and current.

Product appearance structure and working environment requirements

• Equipment size: the volume of the instrument itself 550×500×220mm, net weight 20KG.
• Working environment: working power requires mains AC220V input, power supply
  fluctuation range (170-260V), working environment temperature -10°C to 40°C, working
  humidity 10%~90%, maximum power 750W, it only appears when testing high current.
